Lithium Battery Solar Storage System
Lecuso's series of lithium battery solar storage system are mainly for household use and small commercial use, 500W to 5000W generator optional, and are favored by local solar system providers and end users in many countries.
- Rated loads capacity:500W- 5000W
- Power generation:600WH-4500WH
- Solar panel:Polycrystalline / Monocrystalline
- Battery:LiFePo4 Lithium Battery
- Controller:MPPT
- Solar panel bracket: Roof / Ground type
The solar lithium battery power storage system is a kind of power generation system by integrating the controller, inverter, and battery pack into one integral cabinet and can be used only by connecting with the solar panels. This kind of solar system allows end users to use it just by connecting the solar panels without complicated wiring process. It has played a very good role in promoting the popularization of solar power generation systems.
Solar storage system VS traditional solar power system
Easier
The integrated solar energy storage cabinet system does not require complicated wiring. It is easier and more convenient to use.
Save time
The solar energy storage cabinet system can be used as long as it is connected to the solar panel, without wiring, saving a lot of time to install the system.
Better management
The controller, inverter, and battery are all built-in which are making subsequent maintenance and management more convenient.
More space
The solar energy storage cabinet system covers a small area, a closed design, and strong environmental adaptability.
Our Advantages
Innovative integrated design, convenient transportation, simple installation and use, the first choice for household solar power systems user.
Using MPPT controller, the solar energy conversion efficiency is as high as 98%, and it only takes 5-6 hours per day (with sufficient sunlight) to fully charge.
Built-in brand new lithium battery with large capacity and long service life.
500W to 5000W generator optional, customized solar energy storage solutions is available.
Specification
| Model | MPSG-500W | MPSG-1000W | MPSG-3000W | MPSG-5000W | |
| Battery rated voltage | 12V | 24V | 48V | 48V | |
| INVERTER | |||||
| Rated power | 500W | 1000W | 3000W | 5000W | |
| Input voltage range | 140-275V | ||||
| Output wave | Pure sine wave | ||||
| Specification of built-in lithium battery | 600AH | 1200AH | 2600AH | 4500AH | |
| Communication | RS232 | ||||
| SOLAR INPUT | |||||
| Solar panel rated power | 240W | 480W | 1440W | 1440W | |
| Rated charge current | 20A(MPPT) | 30A(MPPT) | |||
| DC OUTPUT | |||||
| 5 VDC USB output | 2Pieces /MAX 2A | ||||
| 12 VDC output ports | 2Pieces /MAX 2A | ||||
| PHYSICAL | |||||
| Heat dissipation/cooling | Temperature control by intelligent exhaust fan | ||||
| Display | Digital LCD | ||||
| Electricity charging | Yes | ||||
| External size(W × D × H) | 420 × 220 × 270 mm | 430 × 230 × 330 mm | 545 × 507 × 580 mm | ||
| Package size(W × D × H) | 507 × 295 × 355 mm | 512 × 310 × 405 mm | 635 × 600 × 761 mm | ||
